LATHE MACHINE

Light, Medium & Heavy Duty
Nagmani Lathe Machines



Ours is a prominent firm that is engaged in supplying and exporting Lathe Machine. These machines are known for their seamless finish, low maintenance, longer service lives, corrosion resistance, abrasion resistance and easy mounting and installation.

The above mentioned features of our offered Lathe Machine are widely cherished by our patrons and thus we are one of the leading firm that is engaged in this domain.

Also we are specialist in manufacturing geared head lathe machines from light to extra heavy, which are designed to comply with the quality standards of the industries and are manufactured with the finest and highest grade of raw materials to construct the machines.

The company has attained a good reputation in India.Our machines complies with the rigid design, convenient maintenance and optimized performance besides affordable pricing.

CONE PULLEY LIGHT DUTY LATHE

LD(DLX)-177

Cone Pulley Light duty lathe machines are used for small and micro Components and Repairing works to be finished and also used for Engineering technical training institutes.

    Speciality

  • 6" Heavy Cross Slide

  • 4" x 4" Tool-Post

  • Appron With Bushing

  • Tailstock Spindle EN-8

  • Tray With Tool-Box

    Accessories

  • Change Gear Set

  • Chuck Back Plate

  • Spindle Sleeve

  • Dead Centre-2nos

  • Tool Post Key

Light Duty Geared Head Lathe

LAG-165

Light duty Geared Head lathe machines are used for small and micro Components and Engineering technical training institutes and Polytechnic Colleges.

Speciality

  • Flame Hardened Bed Ways

  • Gears made from EN-8 Material

  • hreaded type Spindle with EN-8

  • Accuracy as per IS Standard

  • Border Tray

    Accessories

  • Flame Harden Bed Ways

  • Thread Dial Indicator

  • Change Gear Set -1

  • Tool Post Spanner

  • Dead Centre-2nos.

CONE PULLEY MEDIUM DUTY LATHE

MD-250

Cone Pulley Medium duty Lathe Machine is used for the Tool-room Purpose along with the Medium Size of Components (Industries such as ship building, mining, textile, oil etc.) to be make and power plants, repairing shops, steel rolling mills, workshops, tool room, etc.

Speciality

  • 8" Heavy Cross Slide

  • 5" x 5" Tool Post

  • Double Locking Type Tailstock

  • Square Headstock

  • Heavy Counter

    Accessories

  • Change Gear Set

  • Chuck Back Plate

  • Dog & True Chuck

  • Coolant Pump, Tank

  • Tapper Turning Attachment

Medium Duty Geared Head Lathe

MAG-215/250

Medium Duty Geared Head Lathe Machine is Specially Designed for the high RPM upto 1200 / 8 Speed and also the Main drive of headstock is driven by gears which gives. Machine widely used in Engineering Colleges, Repairing Shop, Tool Room Workshop etc.

Speciality

  • Accuracy as per IS Standard

  • Tailstock Spindle EN-8 Harden

  • Double Locking Type Tailstock

  • Threaded type Spindle with EN-8

  • Gears made from EN-8 Material

    Accessories

  • Face Plate Extra Cuck Plate

  • Three Pin Guide

  • Motorised Coolant Pump With Tank

  • Electric Motor

  • Revolving Centre

Medium Duty Geared Head Deluxe

MAG(DLX)-215/250

Medium Duty Geared Head Lathe Machine is Specially Designed for the high RPM upto 1200 / 8 Speed and also the Main drive of headstock is driven by gears which gives. Machine widely used in Engineering Colleges, Repairing Shop, Tool Room Workshop etc.

Speciality

  • A2-4 type Spindle with EN-8

  • Double Locking Type Tailstock

  • Tailstock Spindle EN-8 Harden

  • Accuracy as per IS Standard

  • Gears made from EN-8 Material

    Accessories

  • Flame Harden Bed Ways

  • Dead Centre-2nos

  • Norton Gear Box

  • Chuck Back Plate

  • Centre Adapter

Cone Pulley Heavy Duty Lathe

HD-250/304

This Cone Pulley Heavy Duty Lathe Machine is widely used in the General application of Engineering such as Automobiles Company, Aerospace, Textile, Die Works, Auto Components Manuacturing and Over and above all type of general Industries Turnining /Threading etc.

Speciality

  • Bushing in pulley

  • Passed through Quality Control

  • Tailstock Spindle EN-8 Harden

  • SKF or Timken make Bearing

  • Flame Hardened Bed Ways

    Accessories

  • Flat Belt or "V" Belt

  • Centre Height 10" or 12"

  • Bush or Tapper Roller Bearing

  • Tapper Turning Attachment

  • Coolant Pump, Tank

CONE PULLEY HEAVY DUTY LATHE

HD-381

This Cone Pulley Heavy Duty Lathe Machine is widely used in the General application of Engineering such as Automobiles Company, Aerospace, Textile, Die Works, Auto Components Manuacturing and Over and above all type of general Industries Turnining /Threading etc.

Speciality

  • Bushing in pulley

  • Passed through Quality Control

  • Tailstock Spindle EN-8 Harden

  • SKF or Timken make Bearing

  • Flame Hardened Bed Ways

    Accessories

  • Spindle Bore 80/105/125/150

  • Norton Gear Box

  • Bush or Tapper Roller Bearing

  • Electric Motor

  • Coolant Pump, Tank

HEAVY DUTY GEARED HEAD LATHE

HAG-267

Heavy Duty Geared Head Lathe Machine is specially Designed for the High RPM Upto 1060. The Gears are equipped to obtain different speeds, which can be more than 12 spindle speeds. This Machine is Widely used in automobiles, aerospace, textile, Die Works , Defense, Rough Turning, Facing Etc.

Speciality

  • A2-8 type Spindle with EN-8

  • Flame Hardened Bed Ways

  • Rigid Headstock design

  • Accuracy as per IS Standard

  • Tailstock Spindle EN-8 Harden

    Accessories

  • Centre Adaptor

  • Flame Harden Bed Ways

  • Norton Gear Box

  • Dead Centre-2nos.

  • Motor Pulley

HEAVY DUTY GEARED HEAD LATHE

HAG-304

Heavy Duty Geared Head Lathe Machine is specially Designed for the High RPM Upto 1060. The Gears are equipped to obtain different speeds, which can be more than 12 spindle speeds. This Machine is Widely used in automobiles, aerospace, textile, Die Works , Defense, Rough Turning, Facing Etc.

Speciality

  • A2-8 type Spindle with EN-8

  • Flame Hardened Bed Ways

  • Rigid Headstock design

  • Accuracy as per IS Standard

  • Tailstock Spindle EN-8 Harden

    Accessories

  • Three Pin Guide

  • Flame Harden Bed Ways

  • Norton Gear Box

  • Thread Dial Indicator

  • Motor Pulley

CONE PULLEY EXTRA HEAVY DUTY LATHE

EX HD-457/508/558

Heavy Duty Geared Head Lathe Machine is specially Designed for the High RPM Upto 1060. The Gears are equipped to obtain different speeds, which can be more than 12 spindle speeds. This Machine is Widely used in automobiles, aerospace, textile, Die Works , Defense, Rough Turning, Facing Etc.

Speciality

  • 17.5" Heavy Double gears

  • Heavy Change Gear Set 1.25"

  • Back side M.S.Panja Gear (Set-4)

  • Heaviest Machine in the segment

  • Both Side Bearing 6206 baring

    Accessories

  • Three Pin Guide

  • Flame Harden Bed Ways

  • Norton Gear Box

  • Thread Dial Indicator

  • Motor Pulley

CONE PULLEY EXTRA HEAVY DUTY LATHE

EX HD-457/508/558/610/660/710/760

Cone Pulley Extra Heavy duty Lathe Machine is used for the Tool-room Purpose along with the Medium Size of Components (Industries such as ship building, mining, textile, oil etc.) to be make and power plants, repairing shops, steel rolling mills, Rubber Roll mill, Extra Heavy Works and many purposes in various industries.

Speciality

  • 17.5" Heavy Double gears

  • Heavy Change Gear Set 1.25"

  • Back side M.S.Panja Gear (Set-4)

  • Heaviest Machine in the segment

  • Both Side Bearing 6206 baring

    Accessories

  • Chuck Back Plate

  • Change Gear Set

  • Spindle Sleeve

  • Tool Post Key

  • Steady Rest

EXTRA HEAVY DUTY GEARED HEAD LATHE

EX HAG-406/457/508

Extra Heavy Duty Geared Head Lathe Machine is specially Designed for the High RPM Upto 310. The Gears are equipped to obtain different speeds, which can be more than 9 Spindle speeds. This Machine is Widely used in Heavy Rubber Roll Mill, Extra Heavy Works, automobiles, power plants, aerospace, Etc

Speciality

  • Accuracy as per IS Standard

  • Tailstock Spindle EN-8 Harden

  • A2-8 type Spindle with EN-8

  • Rigid Headstock design

  • Flame Hardened Bed Ways

    Accessories

  • Chuck Back Plate

  • Change Gear Set

  • Tool Post Spanner

  • Three Pin Guide

  • Norton Gear Box.

EXTRA HEAVY DUTY GEARED HEAD LATHE

EX HAG-558/610/660/710

Extra Heavy Duty Geared Head Lathe Machine is specially Designed for the High RPM Upto 310. The Gears are equipped to obtain different speeds, which can be more than 9 Spindle speeds. This Machine is Widely used in Heavy Rubber Roll Mill, Extra Heavy Works, automobiles, power plants, aerospace, Etc

Speciality

  • Accuracy as per IS Standard

  • Tailstock Spindle EN-8 Harden

  • A2-8 type Spindle with EN-8

  • Rigid Headstock design

  • Flame Hardened Bed Ways

    Accessories

  • Chuck Back Plate

  • Change Gear Set

  • Tool Post Spanner

  • Three Pin Guide

  • Norton Gear Box.

EXTRA HEAVY DUTY GEARED HEAD LATHE

EX HAG-558/610/660/710

Extra Heavy Duty Geared Head Lathe Machine is specially Designed for the High RPM Upto 310. The Gears are equipped to obtain different speeds, which can be more than 9 Spindle speeds. This Machine is Widely used in Heavy Rubber Roll Mill, Extra Heavy Works, automobiles, power plants, aerospace, Etc

Speciality

  • Accuracy as per IS Standard

  • Tailstock Spindle EN-8 Harden

  • A2-8 type Spindle with EN-8

  • Rigid Headstock design

  • Flame Hardened Bed Ways

    Accessories

  • Chuck Back Plate

  • Change Gear Set

  • Tool Post Spanner

  • Three Pin Guide

  • Norton Gear Box.

MEDIUM UNDER COUNTER LATHE

MUC-250

Medium Under Counter Lathe Machine is used for the Tool-room Purpose along with the Medium Size of Components (Industries such as ship building, mining, textile, oil etc.) to be make and power plants, repairing shops, steel rolling mills, workshops, tool room, etc.

Speciality

  • Under/Rear Side Motor

  • Helical gears

  • Rigid Design

  • Bushing in pulley

  • Accuracy as per IS Standard

    Accessories

  • Chuck Back Plate

  • Change Gear Set

  • Spindle Sleeve

  • Dead Centre-2nos.

  • Tool Post Key

HEAVY DUTY UNDER COUNTER LATHE

MUC-250

This Cone Pulley Heavy Duty Lathe Machine is widely used in the General application of Engineering such as Automobiles Company, Aerospace, Textile, Die Works, Auto Components Manuacturing and Over and above all type of general Industries Turning /Threading etc.

Speciality

  • Square Headstock

  • Helical gears

  • Rigid Design

  • Bushing in pulley

  • Accuracy as per IS Standard

    Accessories

  • Chuck Back Plate

  • Change Gear Set

  • Follow Rest

  • Dead Centre-2nos.

  • Steady Rest
